UP-300S
Category：
100T-300T
Keywords：
Injection molding machines
Machine mode：
UP-300S
Description : Union Power brand servo motor injection molding machine
Machine condition: new made according to order.
Place of original: Ningbo city, China.
Contact Union Power team for more details:
+86 13705741165 ( phone / wechat / whatsapp )
Product Details
Detailed display
Technical Parameters
| MACHINE MODEL | UP-300S | |||
| International Size Rating | 1460/300 | |||
| INJECTION UNIT | A | B | C | |
| Screw Diameter | mm | 60 | 65 | 70 |
| Length/Diameter Ratio | L/D | 21.7 | 20 | 18.6 |
| Theoretical Shot Volume | cm | 806 | 946 | 1096 |
| Injection Weight(PS) | g | 725 | 851 | 987 |
| Injection Rate(PS) | g/s | 246 | 293 | 344 |
| Plasticizing Capacity | g/s | 38.9 | 47.6 | 59 |
| Theoretical Injection Pressure | Mpa | 182 | 155 | 134 |
| Maximum Screw Speed | rmp | 0-220 | ||
| Clamping Unit | ||||
| Clamp Tonnage | kN | 3000 | ||
| Toggle Stroke | mm | 590 | ||
| Space Between tie Bars | mm | 620×620 | ||
| Max. Mold Height | mm | 620 | ||
| Min. Mold Height | mm | 220 | ||
| Daylight Opening | mm | 1210 | ||
| Ejector Number | Piece | 9 | ||
| Ejector stroke | mm | 150 | ||
| Ejector tonnage | kN | 70 | ||
| OTHERS | ||||
| System Pressure | Mpa | 16 | ||
| Pump moter Power (servo) | kW | 31.3 | ||
| Heater Power | kW | 18.5 | ||
| Machine Dimension(LxWxH) | mm | 6.3×1.75×2.37 | ||
| Oil tank Capacity | L | 550 | ||
| Machine Weight | t | 9.3 | ||
